PRODUCT CENTER
PRODUCT CATEGORY
Quickly Query What You Want To Know
Model：PD-180BXJ-S
Dimensions：L1270*W710*H1225
Weight：Approx. 350KG
Display：Bilingual version in English and Chinese
Power/Rated voltage：220V\2000W
Cutting Length (mm)：1mm-99999.99mm
Stripping Length (mm)：0.1-300mm
Dimensions：L1270*W710*H1225
Weight：Approx. 350KG
Display：Bilingual version in English and Chinese
Power/Rated voltage：220V\2000W
Cutting Length (mm)：1mm-99999.99mm
Stripping Length (mm)：0.1-300mm
Equipment model：PD-16BXJ-01
Cut wire cores ：1-16Square
Cut wire lengths：0.01-999999.99mm
Stripping length：0.01-100mm
Stripping length：0.01-70mm
Pressure adjustment：Bi-directional (computer regulated pressure)
Blade material ：Tungsten Steel / Swedish HSS
Wire feeding speed ：45-55m/min
Capacity/hour：1500-2000bars/hour
Wire feeding method：12-wheel tracked wire feed
Cutting diameter：2-10mm
Diameter of guide tube：3/4/6/8/10
Detection function：Missing wire detection
Tube swing：Pneumatic
Cut wire cores ：1-16Square
Cut wire lengths：0.01-999999.99mm
Stripping length：0.01-100mm
Stripping length：0.01-70mm
Pressure adjustment：Bi-directional (computer regulated pressure)
Blade material ：Tungsten Steel / Swedish HSS
Wire feeding speed ：45-55m/min
Capacity/hour：1500-2000bars/hour
Wire feeding method：12-wheel tracked wire feed
Cutting diameter：2-10mm
Diameter of guide tube：3/4/6/8/10
Detection function：Missing wire detection
Tube swing：Pneumatic
Model：PD-70BXJ-01
Dimensions：L650*W580*H460mm
Weight：Approx. 80KG
Display：Bilingual version in English and Chinese
Power/Rated voltage：220V\2000W
Cutting Length (mm)：1mm-99999.99mm
Dimensions：L650*W580*H460mm
Weight：Approx. 80KG
Display：Bilingual version in English and Chinese
Power/Rated voltage：220V\2000W
Cutting Length (mm)：1mm-99999.99mm
Model：PD-120BXL-S
Dimensions：L980*W580*H1200
Weight：Approx. 280KG
Display：Bilingual version in English and Chinese
Power/Rated voltage：220V\1.8KW
Cutting Length (mm)：1mm-99999.99mm
Dimensions：L980*W580*H1200
Weight：Approx. 280KG
Display：Bilingual version in English and Chinese
Power/Rated voltage：220V\1.8KW
Cutting Length (mm)：1mm-99999.99mm
Model：PD-120BXL-L
Dimensions：L980*W580*H1200
Weight：Approx. 280KG
Display：Bilingual version in English and Chinese
Power/Rated voltage：220V\2000W
Cutting Length (mm)：1mm-99999.99mm
Dimensions：L980*W580*H1200
Weight：Approx. 280KG
Display：Bilingual version in English and Chinese
Power/Rated voltage：220V\2000W
Cutting Length (mm)：1mm-99999.99mm
Model：PD-WHJ-C-01
Control method：Automatic
Current：Direct current
Operating frequency：20KHZ
Pneumatic pressure：0.1-0.7mpa
Welding area：0.5mm²-30mm²
Control method：Automatic
Current：Direct current
Operating frequency：20KHZ
Pneumatic pressure：0.1-0.7mpa
Welding area：0.5mm²-30mm²
Model：PD-DHJ-W-02
Control method：Automatic
Current：Direct current
Operating frequency：20KHZ
Pneumatic pressure：0.1-0.7mpa
Welding area：0.5mm²-30mm²
Control method：Automatic
Current：Direct current
Operating frequency：20KHZ
Pneumatic pressure：0.1-0.7mpa
Welding area：0.5mm²-30mm²
Model：PD-DHJ-M-03
Control method：Automatic
Current：Direct current
Operating frequency：20KHZ
Pneumatic pressure：0.1-0.7mpa
Welding area：0.5mm²-30mm²
Control method：Automatic
Current：Direct current
Operating frequency：20KHZ
Pneumatic pressure：0.1-0.7mpa
Welding area：0.5mm²-30mm²
Model：PD-DHJ-W-02S
Control method：Automatic
Current：Direct current
Operating frequency：20KHZ
Pneumatic pressure：0.1-0.7mpa
Welding area：4mm²-50mm²
Control method：Automatic
Current：Direct current
Operating frequency：20KHZ
Pneumatic pressure：0.1-0.7mpa
Welding area：4mm²-50mm²
Equipment model：DHJ-ZP250KW-06
Function：Wire cutting, stripping, spot welding and forming, cutting, undercutting
Spot welding method：Medium frequency inverter spot welding
Length of cut line：40mm-200mm（Customizable）
Tare length：Customised to customer requirements
Wire diameter range：5-50Square
Function：Wire cutting, stripping, spot welding and forming, cutting, undercutting
Spot welding method：Medium frequency inverter spot welding
Length of cut line：40mm-200mm（Customizable）
Tare length：Customised to customer requirements
Wire diameter range：5-50Square
Equipment model：DHJ-ZP170KW-02
Function：Copper wire feeding, cutting, spot welding, cutting, and unloading
Spot welding method：Medium frequency inverter spot welding
Length of cut line：40mm-200mm（Customizable）
Tare length：Customised to customer requirements
Wire diameter range：1-30 square feet
Production capacity ：≥1200 bars/hour
Function：Copper wire feeding, cutting, spot welding, cutting, and unloading
Spot welding method：Medium frequency inverter spot welding
Length of cut line：40mm-200mm（Customizable）
Tare length：Customised to customer requirements
Wire diameter range：1-30 square feet
Production capacity ：≥1200 bars/hour
Equipment model：DHJ-ZP170KW-03
Function：Wire cutting, stripping, cutting, feeding of copper, soldering to leads, unloading
Spot welding method：Medium frequency inverter spot welding
Length of cut line：40mm-200mm（Customizable）
Tare length：Customised to customer requirements
Wire diameter range：1-30 square feet
Production capacity：≥1200 bars/hour
Function：Wire cutting, stripping, cutting, feeding of copper, soldering to leads, unloading
Spot welding method：Medium frequency inverter spot welding
Length of cut line：40mm-200mm（Customizable）
Tare length：Customised to customer requirements
Wire diameter range：1-30 square feet
Production capacity：≥1200 bars/hour
Equipment model：DHJ-ZP170KW-01
Function：Wire cutting, stripping, spot-soldering, cutting, undercutting
Spot welding method：Medium frequency inverter spot welding
Length of cut line：40mm-200mm（Customizable）
Tare length：Customised to customer requirements
Wire diameter range：3-30 square feet
Production capacity：≥1200 bars/hour
Function：Wire cutting, stripping, spot-soldering, cutting, undercutting
Spot welding method：Medium frequency inverter spot welding
Length of cut line：40mm-200mm（Customizable）
Tare length：Customised to customer requirements
Wire diameter range：3-30 square feet
Production capacity：≥1200 bars/hour
Model：DZJ-CK-ZX06
Name：Automatic Crimping and Inserting Machine
Function：1-16 wires cut, stripped, crimped, tinned and cased in one go
Wire diameter range：18#-28#Electronic wire
Cut-off length：50-500mm
Tangential accuracy：0.1mm
Stripping length：1-15mm
Name：Automatic Crimping and Inserting Machine
Function：1-16 wires cut, stripped, crimped, tinned and cased in one go
Wire diameter range：18#-28#Electronic wire
Cut-off length：50-500mm
Tangential accuracy：0.1mm
Stripping length：1-15mm
Model：PD-05DT-PX
Function：Wire cutting, single end stripping, double end stripping, double end splitting, single end crimping, single end tinning
Power source：220V/50/60HZ Single Phase
Productivity：Over 24 times/minute (exact production capacity varies according to type of wire, size of wire diameter and type of terminal)
Applicable terminals：XH、PH、2510、Spring-loaded terminals, etc.
Applicable wires：Red and white rows, blue and white rows, coloured rows, grey rows, etc.
Function：Wire cutting, single end stripping, double end stripping, double end splitting, single end crimping, single end tinning
Power source：220V/50/60HZ Single Phase
Productivity：Over 24 times/minute (exact production capacity varies according to type of wire, size of wire diameter and type of terminal)
Applicable terminals：XH、PH、2510、Spring-loaded terminals, etc.
Applicable wires：Red and white rows, blue and white rows, coloured rows, grey rows, etc.
